EC4A16H image
Favorite
EC4A16H image
Favorite
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 14 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description Isolated DC/DC Converters 5-6W 18-36VDC +/-5V +/-500mA 3K ISO
PDF
/
Buying Options
Total Price: USD $11.6
Unit Price: USD $11.602249
≥1 USD $11.602249
≥10 USD $10.945513
≥100 USD $10.325957
≥500 USD $9.741468
≥1000 USD $9.190067
Inventory: 2444
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Current - Output 2 500mA
Nominal Input Voltage 24V
Current - Output 1 500mA
Voltage - Output 2 -5V
Output Power 3W
Current - Output (Max) 500mA 500mA
Voltage - Input (Min) 18V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Input (Max) 36V
Voltage - Isolation 3kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-PDIP-T10
Terminal Position DUAL
Subcategory Other Analog ICs
Power (Watts) 5W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series EC4A (6W)
Published 2015
Operating Temperature -25°C~71°C

Physical

Surface Mount NO
Package / Case 24-DIP Module, 14 Leads
Mounting Type Through Hole

Supply Chain

Factory Lead Time 8 Weeks
