CHB100-24S05
RoHS
RoHS compliant
RoHS compliantPackage Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 100W, Wide Input 18-36Vin, 5Vout
PDF
/
Buying Options
Total Price: USD $75.96
Unit Price: USD $75.9616
≥1 USD $75.9616
≥10 USD $75.37024
≥100 USD $74.77712
≥500 USD $72.40288
≥1000 USD $68.842224
≥3000 USD $64.094536
Inventory: 249
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 57.9mm
Technical
Nominal Input Voltage 24V
Current - Output 1 20A
Control Features Enable, Active High
Output Power 100W
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 84%
Number of Outputs 1
JESD-30 Code R-MDMA-P9
Pin Count 9
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Series CHB100 (100W)
Published 2005
Operating Temperature -40°C~100°C With Derating
Physical
Surface Mount NO
Package / Case Half Brick
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
