BTB05-12S25S
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
ISOLATED DC-DC 3W
PDF
/
Inventory: 7446
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 23.7mm
Height 17.1mm
Technical
Total Power Output-Max 3W
Output Power 3W
Output Current 250mA
Trim/Adjustable Output YES
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 12V
Output Voltage 1.215kV
Voltage - Input (Max) 9V
Voltage - Isolation 500V
Efficiency 82%
Number of Outputs 1
JESD-30 Code R-MDMA-G7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Power (Watts) 3W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, Remote On/Off
Size / Dimension 0.91Lx0.65W x 0.33 H 23.2mmx16.6mmx8.5mm
Series BTB (3W)
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount YES
Package / Case 10-SMD Module, 7 Leads
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
