BLC05-12S50
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
ULTRALOW NOISE ISOLATED DC-DC 6W
PDF
/
Buying Options
Total Price: USD $24.46
Unit Price: USD $24.4552
≥1 USD $24.4552
≥10 USD $24.26336
≥100 USD $24.07592
≥500 USD $22.571023
≥1000 USD $20.690173
≥3000 USD $20.313955
Inventory: 110
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-SMD Module, 7 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~85°C With Derating
Published 2012
Series BLC05 (6W)
Size / Dimension 0.91Lx0.83W x 0.39 H 23.2mmx21.1mmx10.0mm
Feature Adjustable Output, Remote On/Off
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 6W
Technology HYBRID
Terminal Position DUAL
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-MDMA-X7
Number of Outputs 1
Efficiency 80%
Voltage - Isolation 500V
Voltage - Input (Max) 9V
Output Voltage 12V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output YES
Output Current 500mA
Output Power 6W
Total Power Output-Max 6W
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
