HLD15ZEB
RoHS
/
Package 10-DIP Module, 1/2 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.3V 1.8V 60W
PDF
/
Inventory: 2506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Total Power Output-Max 50W
Voltage - Output 2 1.8V
Control Features Enable, Active High
Current - Output (Max) 15A 15A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 3.3V
Output Voltage 3.3V
Voltage - Input (Max) 72V
Voltage - Isolation 1.5kV
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XDMA-P10
Pin Count 10
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
HTS Code 8504.40.85.00
Additional Feature 1.8 V ADDITIONAL OUTPUT AVAILABLE
Power (Watts) 60W
Applications ITE (Commercial)
Terminal Finish TIN LEAD
Type Isolated Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Remote On/Off, OCP, OTP, OVP, UVLO
JESD-609 Code e0
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Series HLD (60W)
Packaging Bulk
Operating Temperature -40°C~100°C
Physical
Surface Mount NO
Package / Case 10-DIP Module, 1/2 Brick
Mounting Type Through Hole
