APH18E48
RoHS
/
Package 9-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 7.25V 130W
PDF
/
Inventory: 2182
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 9-DIP Module
Surface Mount NO
Technical
Operating Temperature -25°C~65°C
Series APH18
Size / Dimension 2.40Lx2.30W x 0.43 H 61.0mmx58.4mmx10.9mm
JESD-609 Code e0
Feature OCP, OTP, OVP
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Type Non-Isolated PoL Module
Terminal Finish TIN LEAD
Applications ITE (Commercial)
Power (Watts) 130W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 92%
Voltage - Input (Max) 75V
Output Voltage 7.25V
Voltage - Output 1 7.25V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 18A
Compliance
RoHS Status Non-RoHS Compliant
Alternative Model
