AEQ15AF48
RoHS
/
Package 7-DIP Module, 1/4 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 5V 3.3V 60W
PDF
/
Inventory: 4840
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Total Power Output-Max 60W
Voltage - Output 2 3.3V
Current - Output (Max) 12A 15A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Input (Max) 75V
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XDMA-P7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Subcategory Other Analog ICs
Power (Watts) 60W
Applications ITE (Commercial)
Terminal Finish TIN LEAD
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off, OCP, OTP, OVP, UVLO
JESD-609 Code e0
Size / Dimension 2.30Lx1.50W x 0.50 H 58.4mmx38.1mmx12.7mm
Series AEQ15 (60W)
Published 2002
Packaging Bulk
Operating Temperature -40°C~100°C
Physical
Surface Mount NO
Package / Case 7-DIP Module, 1/4 Brick
Mounting Type Through Hole
