AA60A-048L-050D033N

Artesyn Embedded Power
RoHS
/
Package 10-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 5V 3.3V 75W
PDF
/
Inventory: 8411
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Total Power Output-Max 75W
Voltage - Output 2 3.3V
Current - Output (Max) 15A 15A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 82%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XDMA-P10
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Subcategory Other Analog ICs
Power (Watts) 75W
Applications ITE (Commercial)
Terminal Finish TIN LEAD
Type Isolated Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off, OTP, OVP, SCP
JESD-609 Code e0
Size / Dimension 2.40Lx2.30W x 0.50 H 61.0mmx58.4mmx12.7mm
Series AA60A (75W)
Published 2002
Packaging Bulk
Operating Temperature -40°C~105°C

Physical

Surface Mount NO
Package / Case 10-DIP Module
Mounting Type Through Hole
