EN6360QI
RoHS
/
Package /
Category Power Supplies - Board Mount / DC DC Converters
Description
ENPIRION EN6360QI DC-DC Switching Buck Step Down Regulator, Adjustable, 2.5V-6.6Vin, 600mV-5.8Vout, 8Aout, QFN-68
PDF
/
Buying Options
Total Price: USD $41.61
Unit Price: USD $41.61475
≥1 USD $41.61475
≥10 USD $34.1449
≥100 USD $33.07805
≥500 USD $32.0112
≥1000 USD $30.94435
Inventory: 5105
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 8mm
Length 11mm
Height Seated (Max) 3.05mm
Technical
Switching Frequency-Max 1500kHz
Switcher Configuration BUCK
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 6.6V
Output Current-Max 8A
Control Mode VOLTAGE-MODE
Input Voltage (Min) 2.5V
Analog IC - Other Type SWITCHING REGULATOR
Temperature Grade INDUSTRIAL
Input Voltage-Nom 5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code R-XQCC-N68
Pin Count 68
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code compliant
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Subcategory Switching Regulator or Controllers
HTS Code 8542.39.00.01
Additional Feature ADJUSTABLE OUTPUT MODE FROM 0.6 TO 5.8 VOLT
Terminal Finish MATTE TIN
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3
Pbfree Code icon-pbfree yes
JESD-609 Code e3
Physical
Number of Terminals 68
Surface Mount YES
