QBVW025A0B54Z
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 1/4 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 12V 300W
PDF
/
Inventory: 7587
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP Module, 1/4 Brick
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Barracuda? QBDW025A0B (300W)
Size / Dimension 2.30Lx1.45W x 0.50 H 58.4mmx36.8mmx12.7mm
Feature Remote On/Off, OCP, OTP, OVP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 300W
Number of Outputs 1
Efficiency 96%
Voltage - Isolation 2.25kV
Voltage - Input (Max) 75V
Voltage - Output 1 12V
Voltage - Input (Min) 36V
Current - Output (Max) 25A
Control Features Enable, Active High
Compliance
RoHS Status RoHS Compliant
