DC0923812M2B-BT0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN 12VDC 92X38MM 4WIRES
PDF
/
Inventory: 4566
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Static Pressure 0.860 in H2O (214.2 Pa)
Noise 58.0 dB(A)
Air Flow 109.2 CFM (3.06m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 5000 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, cURus, TUV
Current Rating (Amps) 0.900A
Voltage - Rated 12VDC
Power (Watts) 10.8W
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Size / Dimension Square - 92mm Lx92mm H
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Polybutylene Terephthalate (PBT), Glass Filled
Material - Frame Polybutylene Terephthalate (PBT), Glass Filled
Weight 0.441lb 200.00g
Supply Chain
Factory Lead Time 12 Weeks
