DC0603812L2B-BT0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN 12VDC 60X38MM 4WIRES
PDF
/
Inventory: 1633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Weight 0.32lb 145.15g
Material - Frame Polybutylene Terephthalate (PBT), Glass Filled
Material - Blade Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature 14~158°F -10°C~70°C
Size / Dimension Square - 60mm Lx60mm H
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 4 Wire Leads
Power (Watts) 12W
Voltage - Rated 12VDC
Current Rating (Amps) 1.00A
Approval Agency CE, cURus, TUV
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 10000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 55.0 CFM (1.54m3/min)
Noise 57.0 dB(A)
Static Pressure 1.410 in H2O (351.2 Pa)
Compliance
RoHS Status ROHS3 Compliant
