FDD1-17251EBLW34
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 172X51MM 48VDC WIRE
PDF
/
Inventory: 9845
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Weight 2.5lbs 1.1kg
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature -4~158°F -20°C~70°C
Published 2014
Series HPLC, FDD1-17251
Size / Dimension Rectangular/Rounded - 172mm Lx151mm H
Feature Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Max Operating Temperature 158°C
Min Operating Temperature -4°C
Power (Watts) 21.6W
Voltage - Rated 48VDC
Current Rating (Amps) 0.450A
Max Power Dissipation 21.6W
Ingress Protection IP54 - Dust Protected, Water Resistant
Current Rating 450mA
Approval Agency CE, cURus, TUV
Lifetime @ Temp 50000 Hrs @ 25°C
RPM 3200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 255.0 CFM (7.14m3/min)
Noise 56.0 dB(A)
Static Pressure 0.736 in H2O (183.3 Pa)
Dimensions
Width 51.00mm
Compliance
RoHS Status ROHS3 Compliant
Ratings IP54, Water Resistant
