8414GM
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 80X25MM 24VDC WIRE
PDF
/
Inventory: 6606
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Thermal Support Device Type DC FAN
Voltage Range 12V~28VDC
Noise 29.0 dB(A)
Air Flow 27.0 CFM (0.756m3/min)
Fan Type Tubeaxial
Bearing Type Sintec
Max Power Dissipation 1.2W
Voltage - Rated DC 24V
Power Rating 1.2W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension Square - 80mm Lx80mm H
Series 8400
Physical
Material - Blade Polyamide (PA), Nylon
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Weight 0.31lb 140.61g
Housing Material Polymer
Package / Case Axial
Mount Flanges
