8214J/2H3
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
EBM PAPST 8214J/2H3Axial Fan, Tubeaxial, Square, Wire Leaded, Ball, 8200J Series, 24 VDC, 80 mm, 38 mm
PDF
/
Inventory: 6779
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Flanges
Package / Case Axial
Material Plastic
Housing Material Polybutylene
Weight 0.44lb 199.58g
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material - Blade Polyamide (PA), Nylon, Fiberglass Reinforced
Technical
Operating Temperature 14~140°F -10°C~60°C
Packaging Bulk
Series 8200J
Size / Dimension Square - 80mm Lx80mm H
Feature Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Voltage - Rated 24VDC
Power Rating 25W
Max Power Dissipation 25W
Depth 38mm
Lead Length 310mm
Operating Supply Voltage 24V
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 112.0 CFM (3.14m3/min)
Power Consumption 25W
Noise 66.0 dB(A)
Voltage Range 12V~27.6VDC
Thermal Support Device Type DC FAN
Dimensions
Height 80mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
