622HH
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 60X25.4MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $31.44
Unit Price: USD $31.4424
≥1 USD $31.4424
≥10 USD $28.71792
≥100 USD $27.6276
≥500 USD $25.80981
≥1000 USD $23.81053
≥3000 USD $23.446984
Inventory: 367
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Flanges
Package / Case Axial
Material Plastic
Housing Material Polybutylene
Weight 0.187lb 84.82g
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material - Blade Polyamide (PA), Nylon, Fiberglass Reinforced
Technical
Operating Temperature -4~158°F -20°C~70°C
Series 620
Size / Dimension Square - 60mm Lx60mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Color Black
Power Rating 3.5W
Voltage - Rated DC 12V
Max Power Dissipation 3.5W
Depth 60mm
Approval Agency CE, CSA, UL, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 65000 Hrs @ 40°C
Cable Length 310mm
RPM 8200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 33.0 CFM (0.924m3/min)
Power Consumption 3.5W
Noise 43.0 dB(A)
Voltage Range 8V~15VDC
Thermal Support Device Type DC FAN
Dimensions
Height 60mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
