4414F/2
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
EBM PAPST 4414F/2Axial Fan, Compact, Ball, 4400F Series, 24 VDC, 119 mm, 25 mm, 100.1 cu.ft/min, 170 m/h
PDF
/
Buying Options
Total Price: USD $40.29
Unit Price: USD $40.2864
≥1 USD $40.2864
≥10 USD $36.7928
≥100 USD $35.395712
≥500 USD $33.06688
≥1000 USD $30.505376
≥3000 USD $30.03968
Inventory: 439
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Screw
Package / Case Axial
Number of Pins 3
Housing Material Plastic
Weight 0.386lb 175.09g
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material - Blade Polyamide (PA), Nylon, Fiberglass Reinforced
Technical
Operating Temperature -4~140°F -20°C~60°C
Series 4400F
Size / Dimension Square - 119mm Lx119mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 3 Wire Leads
Voltage - Rated 24VDC
Power Rating 5W
Depth 25mm
Lead Length 310mm
Operating Supply Voltage 24V
Lifetime @ Temp 60000 Hrs @ 40°C
RPM 2900 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 100.1 CFM (2.80m3/min)
Power Consumption 5W
Noise 43.0 dB(A)
Voltage Range 12V~28VDC
Dimensions
Height 119mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
