4374-123
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fans DC Tubeaxial Fan
PDF
/
Inventory: 7741
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Weight 0.485lb 220.00g
Material - Frame Polybutylene Terephthalate (PBT)
Material - Blade Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -4~167°F -20°C~75°C
Size / Dimension Square - 119mm Lx119mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Terminals
Power (Watts) 6.8W
Voltage - Rated 24VDC
Current Rating (Amps) 0.280A
Approval Agency VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 105.9 CFM (2.97m3/min)
Noise 47.0 dB(A)
Voltage Range 12V~28VDC
Compliance
RoHS Status RoHS Compliant
