4312MT
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
EBM PAPST 4312MTAxial Fan, Compact, Ball, 4300 Series, 12 VDC, 119 mm, 32 mm, 81.2 cu.ft/min, 138 m/h
PDF
/
Inventory: 4916
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Thermal Support Device Type DC FAN
Voltage Range 8V~15VDC
Noise 39.0 dB(A)
Power Consumption 3.3W
Air Flow 81.2 CFM (2.27m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2300 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Lead Length 310mm
Approval Agency CE, CSA, UL, VDE
Max Power Dissipation 3.3W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Temperature Sensor
Size / Dimension Square - 119mm Lx119mm H
Series 4300
Operating Temperature -4~149°F -20°C~65°C
Physical
Material - Blade Polyamide (PA), Nylon, Fiberglass Reinforced
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Weight 0.485lb 219.99g
Package / Case Axial
