4214H
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 24V 5.3W 3400RPM 108.3CFM 49dB Flange Mount
PDF
/
Inventory: 8589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Flanges
Package / Case Axial
Material Plastic
Housing Material Polybutylene
Weight 0.639lb 289.85g
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material - Blade Polyamide (PA), Nylon, Fiberglass Reinforced
Technical
Operating Temperature -4~149°F -20°C~65°C
Series 4200
Size / Dimension Square - 119mm Lx119mm H
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power Rating 5.3W
Voltage - Rated DC 24V
Max Power Dissipation 5.3W
Depth 119mm
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 60000 Hrs @ 40°C
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 108.3 CFM (3.03m3/min)
Noise 49.0 dB(A)
Voltage Range 12V~28VDC
Thermal Support Device Type DC FAN
Dimensions
Height 119mm
Thickness 38mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
