412FM
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fans 40x10mm, 12VDC 3.5CFM/0.6W/Sintec
PDF
/
Inventory: 3265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Flanges
Package / Case Axial
Material Plastic
Housing Material Polybutylene
Weight 0.038lb 17.24g
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material - Blade Polyamide (PA), Nylon, Fiberglass Reinforced
Technical
Operating Temperature -4~158°F -20°C~70°C
Series 400F
Size / Dimension Square - 40mm Lx40mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 600mW
Max Power Dissipation 600mW
Depth 40mm
Approval Agency CSA, UL, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 45000 Hrs @ 20°C
Cable Length 310mm
RPM 4300 RPM
Bearing Type Sintec
Fan Type Tubeaxial
Air Flow 3.5 CFM (0.098m3/min)
Power Consumption 600mW
Noise 16.5 dB(A)
Voltage Range 10V~14VDC
Thermal Support Device Type DC FAN
Rated Power 3.8W
Dimensions
Height 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
