3412
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X25.4MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $61.04
Unit Price: USD $61.0368
≥1 USD $61.0368
≥10 USD $54.252
≥100 USD $44.758208
≥500 USD $40.689264
Inventory: 227
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Thickness 25mm
Width 25.4mm
Height 92mm
Technical
Thermal Support Device Type DC FAN
Voltage Range 7V~15VDC
Noise 36.0 dB(A)
Air Flow 49.0 CFM (1.37m3/min)
Fan Type Tubeaxial
Bearing Type Ball
Nominal Supply Current 200mA
Operating Supply Voltage 12V
Operating Temperature (Max) 75°C
Depth 92mm
Max Power Dissipation 2.4W
Voltage - Rated DC 12V
Power Rating 2.4W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension Square - 92mm Lx92mm H
Series 3400
Physical
Material - Blade Polyamide (PA), Nylon, Fiberglass Reinforced
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Weight 0.31lb 140.61g
Housing Material Polybutylene
Material Plastic
Package / Case Axial
Mount Flanges
