3314
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
EBM PAPST 3314 Axial Fan, Tubeaxial, Square, Wire Leaded, Ball, 24 VDC, 92 mm, 32 mm, 47 cu.ft/min, 80 m/h
PDF
/
Buying Options
Total Price: USD $3.07
Unit Price: USD $3.0712
≥1 USD $3.0712
Inventory: 195
Minimum: 1
-
+
Technical Details
Physical
Mount Flanges
Package / Case Axial
Material Plastic, Polybutylene
Housing Material Polybutylene
Weight 0.419lb 190.06g
Material - Frame Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material - Blade Polyamide (PA), Nylon, Fiberglass Reinforced
Technical
Operating Temperature -4~167°F -20°C~75°C
Series 3300
Size / Dimension Square - 92mm Lx92mm H
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power Rating 2.6W
Voltage - Rated DC 24V
Max Power Dissipation 2.6W
Depth 92mm
Approval Agency CSA, UL, VDE
Operating Supply Voltage 24V
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 47.1 CFM (1.32m3/min)
Power Consumption 2.4W
Noise 37.0 dB(A)
Voltage Range 12V~28VDC
Thermal Support Device Type DC FAN
Dimensions
Height 92mm
Thickness 32mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Contains Lead
Alternative Model
