THB0948AE
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X38MM 48VDC WIRE
PDF
/
Buying Options
Total Price: USD $29.23
Unit Price: USD $29.2336
≥1 USD $29.2336
≥10 USD $27.19728
≥100 USD $24.477376
≥500 USD $22.437712
≥1000 USD $21.077892
≥3000 USD $18.358173
Inventory: 450
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Static Pressure 3.089 in H2O (769.5 Pa)
Voltage Range 36V~60VDC
Noise 72.5 dB(A)
Air Flow 162.5 CFM (4.55m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 13000 RPM
Approval Agency CE, TUV, UL
Current Rating 760mA
Reach Compliance Code unknown
Max Power Dissipation 36.5W
Current Rating (Amps) 0.760A
Voltage - Rated 48VDC
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Size / Dimension Square - 92mm Lx92mm H
Series THB
Published 2010
Physical
Material - Frame Plastic
Weight 0.496lb 224.98g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
