THA0948BE
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X38MM 48VDC WIRE
PDF
/
Inventory: 4411
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 38.00mm
Length 92mm
Height 92mm
Technical
Static Pressure 3.020 in H2O (752.3 Pa)
Voltage Range 30V~60VDC
Noise 71.0 dB(A)
Air Flow 189.7 CFM (5.31m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 9500 RPM
Approval Agency CE, cURus, TUV
Current Rating 1.4A
Max Power Dissipation 67.2W
Current Rating (Amps) 1.4A
Power Rating 67.2W
Voltage - Rated 48VDC
Power (Watts) 67.2W
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature PWM Control, Speed Sensor (Tach)
Size / Dimension Square - 92mm Lx92mm H
Series THA
Published 2010
Physical
Material - Blade Plastic
Material - Frame Aluminum
Weight 1.102lb 500.0g
Housing Material Aluminium
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
