TDA1748AG image
Favorite
TDA1748AG image
Favorite
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 172X50.8MM 48VDC WIRE
PDF
/
Inventory: 5768
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 50.80mm
Length 172mm
Height 150mm

Technical

Static Pressure 2.820 in H2O (702.5 Pa)
Voltage Range 30V~60VDC
Noise 71.0 dB(A)
Air Flow 413.0 CFM (11.56m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 5400 RPM
Life (Hours) 80000 hours
Lifetime @ Temp 80000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 1.85A
Max Power Dissipation 88.8W
Current Rating (Amps) 1.85A
Power Rating 88.8W
Voltage - Rated 48VDC
Power (Watts) 88.8W
Min Operating Temperature 14°C
Max Operating Temperature 158°C
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature PWM Control, Speed Sensor (Tach)
Size / Dimension Round - 172mm Dia
Series TDA
Published 2011
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Blade Plastic
Material - Frame Aluminum
Weight 1.8lbs 816.5g
Housing Material Aluminium
Package / Case Axial

Supply Chain

Factory Lead Time 19 Weeks
