QFR0812UHE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 80X80X38MM 12V WIRE
PDF
/
Inventory: 7416
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Static Pressure 1.335 in H2O (332.5 Pa)
Voltage Range 7V~13.2VDC
Noise 60.0 dB(A)
Air Flow 105.2 CFM (2.95m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 9000 RPM
Approval Agency CE, CSA, UL, VDE
Reach Compliance Code unknown
Current Rating (Amps) 1.15A
Voltage - Rated 12VDC
Power (Watts) 13.8W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Locked Rotor Protection
Size / Dimension Square - 80mm Lx80mm H
Series QFR
Published 2016
Physical
Material - Frame Plastic
Weight 0.353lb 160.12g
Supply Chain
Factory Lead Time 18 Weeks
