PFM0612XHEB7T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
60X38MM 12V DC FAN W/ PWM CONTRO
PDF
/
Inventory: 1536
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 38.00mm
Technical
Static Pressure 2.343 in H2O (583.6 Pa)
Voltage Range 10.8V~12.6VDC
Noise 65.1 dB(A)
Air Flow 64.4 CFM (1.80m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 18500 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency cURus, TUV
Current Rating (Amps) 1.15A
Voltage - Rated 12VDC
Power (Watts) 13.8W
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature PWM Control, Speed Sensor (Tach)
Size / Dimension Square - 60mm Lx60mm H
Series PFM - Three-Phase
Published 2012
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.218lb 98.88g
Supply Chain
Factory Lead Time 19 Weeks
