PFC1224DE-6L52

Delta Electronics
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description PFC Series 5500 RPM 120 x 120 x 38 mm 252.85 CFM 24 V Ball Bearing Fan
PDF
/
Inventory: 9691
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 38.00mm

Technical

Static Pressure 1.412 in H2O (351.7 Pa)
Voltage Range 14V~26.5VDC
Noise 66.5 dB(A)
Air Flow 252.8 CFM (7.08m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 5500 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 2A
Max Power Dissipation 48W
Current Rating (Amps) 2A
Voltage - Rated 24VDC
Power (Watts) 48W
Min Operating Temperature 14°C
Max Operating Temperature 158°C
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature PWM Control, Speed Sensor (Tach)
Size / Dimension Square - 120mm Lx120mm H
Series PFC
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Blade Plastic
Material - Frame Plastic
Weight 0.838lb 380.11g
Package / Case Axial
