PFB2048HT-TP37

Delta Electronics
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 208X70MM 48VDC WIRE
PDF
/
Inventory: 6665
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height 200mm

Technical

Static Pressure 2.290 in H2O (570.4 Pa)
Voltage Range 36V~56VDC
Noise 68.5 dB(A)
Air Flow 569.5 CFM (15.95m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4800 RPM
Life (Hours) 80000 hours
Lifetime @ Temp 80000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 2.36A
Max Power Dissipation 113W
Power Rating 113.28W
Voltage - Rated 48VDC
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Size / Dimension Round - 208mm Dia
Series PFB
Published 2010
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Blade Plastic
Material - Frame Aluminum
Weight 3.5lbs 1.6kg
Housing Material Aluminium
Package / Case Axial

Supply Chain

Factory Lead Time 18 Weeks
