PFB1248GHE-R00

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN 120X120X38MM
PDF
/
Inventory: 5460
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic

Technical

Series PFB
Size / Dimension Square - 120mm Lx120mm H
Feature Locked Rotor Sensor
Part Status Active
Termination 3 Wire Leads
Power (Watts) 32.64W
Voltage - Rated 48VDC
Power Rating 23.64W
Current Rating (Amps) 0.680A
Approval Agency CE, CSA, UR, VDE
RPM 4800 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 217.8 CFM (6.10m3/min)
Noise 64.0 dB(A)
Voltage Range 30V~56VDC
Static Pressure 1.075 in H2O (267.8 Pa)

Dimensions

Height 120mm
Length 120mm
Width 38.00mm

Compliance

RoHS Status ROHS3 Compliant
