PFB1248GHE
RoHS
RoHS compliant
RoHS compliantPackage 217
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 48V 0.68A 32.64W 4800RPM 217.8CFM 64dB Flange Mount
PDF
/
Inventory: 6824
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Package / Case 217
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series PFB
Size / Dimension Square - 120mm Lx120mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 32.64W
Voltage - Rated 48VDC
Power Rating 23.64W
Current Rating (Amps) 0.680A
Depth 120mm
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 4800 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 217.8 CFM (6.10m3/min)
Noise 64.0 dB(A)
Voltage Range 30V~56VDC
Static Pressure 1.075 in H2O (267.8 Pa)
Dimensions
Height 120mm
Length 120mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
