PFB1248EHE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 48V 0.45A 21.6W 4000RPM 181.27CFM 59dB Flange Mount
PDF
/
Inventory: 6103
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 38.00mm
Length 120mm
Height 120mm
Technical
Static Pressure 0.751 in H2O (187.0 Pa)
Voltage Range 30V~56VDC
Noise 59.0 dB(A)
Air Flow 181.3 CFM (5.08m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4000 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.450A
Power Rating 21.6W
Voltage - Rated 48VDC
Power (Watts) 21.6W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 120mm Lx120mm H
Series PFB
Published 2012
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Housing Material Plastic
Supply Chain
Factory Lead Time 16 Weeks
