PFB0948UHE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 48V 0.6A 28.8W 7000RPM 153.52CFM 64dB Flange Mount
PDF
/
Inventory: 3903
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series PFB
Size / Dimension Square - 92mm Lx92mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 28.8W
Voltage - Rated 48VDC
Power Rating 28.8W
Current Rating (Amps) 0.600A
Lifetime @ Temp 50000 Hrs @ 40°C
RPM 7000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 153.5 CFM (4.30m3/min)
Noise 64.0 dB(A)
Voltage Range 28V~56VDC
Static Pressure 1.449 in H2O (360.9 Pa)
Dimensions
Height 92mm
Length 92mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
