PFB0948EHE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X92X38MM 48V WIRE
PDF
/
Inventory: 4076
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges
Weight 0.551lb 249.93g
Material - Frame Plastic
Technical
Published 2011
Series PFB
Size / Dimension Square - 92mm Lx92mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 48VDC
Power Rating 10.08W
Current Rating (Amps) 0.210A
Max Power Dissipation 10.08W
Current Rating 210mA
Approval Agency CE, CSA, UL, VDE
Operating Temperature (Max) 60°C
Operating Temperature (Min) -10°C
RPM 4800 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 103.7 CFM (2.90m3/min)
Noise 54.0 dB(A)
Voltage Range 28V~56VDC
Static Pressure 0.691 in H2O (172.1 Pa)
Thermal Support Device Type DC FAN
Life Expectancy 50000 h
Dimensions
Height 92mm
Width 38mm
Compliance
RoHS Status ROHS3 Compliant
