PFB0924UHE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN 92X92X38MM
PDF
/
Buying Options
Total Price: USD $22.07
Unit Price: USD $22.068491
≥1 USD $22.068491
≥10 USD $30.8408
≥100 USD $29.8775
≥500 USD $28.91325
≥1000 USD $27.94995
Inventory: 10
Minimum: 1
-
+
Technical Details
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series PFB
Size / Dimension Square - 92mm Lx92mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 24.48W
Voltage - Rated 24VDC
Power Rating 24.48W
Current Rating (Amps) 1.02A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 50000 Hrs @ 40°C
RPM 7000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 153.5 CFM (4.30m3/min)
Noise 64.0 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 1.449 in H2O (360.9 Pa)
Dimensions
Height 92mm
Length 92mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
