PFB0848GHE
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 48V 0.27A 12.96W 6100RPM 86.44CFM 55.5dB Flange Mount
PDF
/
Buying Options
Total Price: USD $27.85
Unit Price: USD $27.847774
≥1 USD $27.847774
≥10 USD $26.271479
≥100 USD $24.784417
≥500 USD $23.381537
≥1000 USD $22.058046
Inventory: 1168
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges
Package / Case Axial
Weight 0.452lb 205.02g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2011
Series PFB
Size / Dimension Square - 80mm Lx80mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 48VDC
Power Rating 12.96W
Current Rating (Amps) 0.270A
Max Power Dissipation 13W
Reach Compliance Code unknown
Current Rating 270mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 50000 Hrs @ 40°C
Life (Hours) 50000 hours
RPM 6100 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 86.4 CFM (2.42m3/min)
Noise 55.5 dB(A)
Voltage Range 28V~56VDC
Static Pressure 0.898 in H2O (223.7 Pa)
Dimensions
Height 80mm
Compliance
RoHS Status ROHS3 Compliant
