PFB0824DHE-T50F
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 80X38MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $38.89
Unit Price: USD $38.8872
≥1 USD $38.8872
≥10 USD $36.17416
≥100 USD $32.556832
≥500 USD $29.843634
≥1000 USD $28.034987
≥3000 USD $24.417554
Inventory: 817
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.452lb 205.02g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2006
Series PFB
Size / Dimension Square - 80mm Lx80mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Max Operating Temperature 140°C
Min Operating Temperature 14°C
Power (Watts) 32.4W
Voltage - Rated 24VDC
Current Rating (Amps) 1.35A
Max Power Dissipation 32.4W
Current Rating 1.35A
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 50000 Hrs @ 40°C
Life (Hours) 50000 hours
RPM 9000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 132.6 CFM (3.71m3/min)
Noise 65.0 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 2.030 in H2O (505.7 Pa)
Dimensions
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
