PFB0812UHE
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 80X38MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $26.68
Unit Price: USD $26.678528
≥1 USD $26.678528
≥10 USD $25.168424
≥100 USD $23.7438
≥500 USD $22.399808
≥1000 USD $21.13189
Inventory: 2665
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 80mm
Technical
Static Pressure 1.368 in H2O (340.8 Pa)
Voltage Range 7V~13.2VDC
Noise 61.0 dB(A)
Air Flow 107.3 CFM (3.00m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 7500 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 1.55A
Reach Compliance Code unknown
Max Power Dissipation 18.6W
Power Rating 18.48W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 80mm Lx80mm H
Series PFB
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.441lb 200.03g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
Alternative Model
