PFB0812EHE-F00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN 80X80X38MM
PDF
/
Inventory: 9157
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 38.00mm
Length 80mm
Height 80mm
Technical
Static Pressure 0.767 in H2O (191.0 Pa)
Voltage Range 7V~13.2VDC
Noise 53.0 dB(A)
Air Flow 79.4 CFM (2.22m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 5600 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.720A
Power Rating 8.64W
Voltage - Rated 12VDC
Power (Watts) 8.64W
Termination 3 Wire Leads
Part Status Active
Feature Locked Rotor Protection, Speed Sensor (Tach)
Size / Dimension Square - 80mm Lx80mm H
Series PFB
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Housing Material Plastic
