PFB0812DHE-TYNT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fans Axial Fan, 80x38mm 12VDC, Ball, PWM
PDF
/
Inventory: 2945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 38.00mm
Technical
Static Pressure 2.030 in H2O (505.7 Pa)
Voltage Range 10.8V~13.2VDC
Noise 66.0 dB(A)
Air Flow 132.6 CFM (3.71m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 9000 RPM
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, cURus, VDE
Ingress Protection IP55 - Dust Protected, Water Resistant
Current Rating (Amps) 2.75A
Voltage - Rated 12VDC
Power (Watts) 33W
Termination 4 Wire Leads
Part Status Active
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Size / Dimension Square - 80mm Lx80mm H
Series PFB
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Supply Chain
Factory Lead Time 20 Weeks
