PFB0612SHE-TZM8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fans DC Fan, 60x38mm 12VDC, Ball, IP55
PDF
/
Inventory: 9559
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series PFB
Size / Dimension Square - 60mm Lx60mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 5.76W
Voltage - Rated 12VDC
Current Rating (Amps) 0.480A
Ingress Protection IP55 - Dust Protected, Water Resistant
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 8000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 43.6 CFM (1.22m3/min)
Noise 50.5 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.918 in H2O (228.7 Pa)
Dimensions
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
