KFB2348HHUAYQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 225X99MM ROUND
PDF
/
Inventory: 2370
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series KFB
Size / Dimension Round - 225mm Dia
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Part Status Active
Termination 4 Wire Leads
Power (Watts) 105.6W
Voltage - Rated 48VDC
Current Rating (Amps) 2.20A
Ingress Protection IP54 - Dust Protected, Water Resistant
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 2600 RPM
Bearing Type Ball
Fan Type Motorized Impellers
Air Flow 735.1 CFM (20.58m3/min)
Noise 71.0 dB(A)
Voltage Range 36V~60VDC
Static Pressure 1.990 in H2O (495.7 Pa)
Dimensions
Width 99.00mm
Compliance
RoHS Status ROHS3 Compliant
