KFB1748EHS

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Ball Bearing 48V 1.15A 55.2W 4200RPM 297.39CFM 73.5dB Flange Mount
PDF
/
Inventory: 5044
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 54.00mm

Technical

Static Pressure 2.361 in H2O (588.1 Pa)
Voltage Range 28V~60VDC
Noise 73.5 dB(A)
Air Flow 289.4 CFM (8.10m3/min)
Fan Type Motorized Impellers
Bearing Type Ball
RPM 4200 RPM
Operating Supply Voltage 48V
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 1.15A
Power Rating 55.2W
Voltage - Rated 48VDC
Power (Watts) 55.2W
Termination 2 Wire Leads
Part Status Active
Size / Dimension Round - 175mm Dia
Series KFB
Published 2016

Physical

Material - Blade Plastic
Material - Frame Aluminum

Supply Chain

Factory Lead Time 17 Weeks
