KFB1724EHS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 24V 2.3A 55.2W 4200RPM 297.39CFM 73.5dB Flange Mount
PDF
/
Inventory: 5531
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Flanges
Material - Frame Aluminum
Material - Blade Plastic
Technical
Published 2005
Series KFB
Size / Dimension Round - 175mm Dia
Part Status Active
Termination 2 Wire Leads
Power (Watts) 55.2W
Voltage - Rated 24VDC
Power Rating 55.2W
Current Rating (Amps) 2.30A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 24V
RPM 4200 RPM
Bearing Type Ball
Fan Type Motorized Impellers
Air Flow 297.4 CFM (8.33m3/min)
Noise 73.5 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 2.361 in H2O (588.1 Pa)
Dimensions
Width 54.00mm
Compliance
RoHS Status ROHS3 Compliant
