KFB1248EHSB80
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
120X54MM 48V DC BLOWER W/PWM CO
PDF
/
Inventory: 6195
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Static Pressure 1.347 in H2O (335.5 Pa)
Voltage Range 36V~57VDC
Noise 61.0 dB(A)
Air Flow 174.8 CFM (4.89m3/min)
Fan Type Motorized Impellers
Bearing Type Ball
RPM 4060 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, cURus, VDE
Current Rating (Amps) 0.450A
Voltage - Rated 48VDC
Power (Watts) 21.6W
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Size / Dimension Round - 120mm Dia
Series KFB
Published 2012
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Aluminum
Supply Chain
Factory Lead Time 19 Weeks
