GFM0412SS-DE1PB7Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
40X56MM 12V DC FAN W/ PWM CONTRO
PDF
/
Buying Options
Total Price: USD $37.34
Unit Price: USD $37.3384
≥1 USD $37.3384
≥10 USD $34.73448
≥100 USD $31.260768
≥500 USD $28.655792
≥1000 USD $26.919112
≥3000 USD $23.445664
Inventory: 387
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Weight 0.225lb 102.06g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2012
Series GFM - Three-Phase
Size / Dimension Square - 40mm Lx40mm H
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads per Fan
Power (Watts) 12.6W
Voltage - Rated 12VDC
Current Rating (Amps) 1.10A
Approval Agency cULus, TUV
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 19000 Front, 19250 Rear
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Air Flow 21.6 CFM (0.605m3/min)
Noise 68.5 dB(A)
Voltage Range 10.8V~12.6VDC
Static Pressure 3.416 in H2O (850.9 Pa)
Dimensions
Width 56.00mm
Compliance
RoHS Status ROHS3 Compliant
