GFC0812DW-SM00B7P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
80X80MM 12V DC FAN W/PWM CONTROL
PDF
/
Buying Options
Total Price: USD $68.46
Unit Price: USD $68.45639
≥1 USD $68.45639
≥10 USD $64.581502
≥100 USD $60.925943
≥500 USD $57.477304
≥1000 USD $54.223876
Inventory: 1092
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Weight 0.851lb 386.01g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2010
Series GFC - Three-Phase
Size / Dimension Square - 80mm Lx80mm H
Feature PWM Control, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads per Fan
Power (Watts) 62.4W
Voltage - Rated 12VDC
Current Rating (Amps) 5.2A
Approval Agency CE, cURus, TUV
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 12000 Front, 10500 Rear
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Air Flow 167.0 CFM (4.68m3/min)
Noise 74.5 dB(A)
Voltage Range 10.8V~12.6VDC
Static Pressure 4.170 in H2O (1038.7 Pa)
Dimensions
Width 80.00mm
Compliance
RoHS Status ROHS3 Compliant
