GFC0812DW-DV55

Delta Electronics
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 80X80X76MM 12V DC FAN WITH SPEED SENSOR (TACH) AND PWM SPEED
PDF
/
Inventory: 2573
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Package / Case Axial
Weight 0.886lbs 401.88g
Material - Frame Plastic
Material - Blade Plastic

Technical

Operating Temperature 14~158°F -10°C~70°C
Packaging Bulk
Published 2010
Series GFC
Size / Dimension Square - 80mm Lx80mm H
Feature PWM Control, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads per Fan
Max Operating Temperature 158°C
Min Operating Temperature 14°C
Power (Watts) 69.9W
Voltage - Rated 12VDC
Current Rating (Amps) 5.8A
Max Power Dissipation 69.9W
Current Rating 5.8A
Approval Agency CE, cURus, TUV
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 12000 Front, 10500 Rear
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Air Flow 165.3 CFM (4.63m3/min)
Noise 76.7 dB(A)
Voltage Range 10.8V~12.6VDC
Static Pressure 3.990 in H2O (993.9 Pa)

Dimensions

Width 80.00mm

Compliance

RoHS Status ROHS3 Compliant
