GFC0812DW-CN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
PWM
PDF
/
Inventory: 4109
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 80.00mm
Technical
Static Pressure 4.470 in H2O (1113.4 Pa)
Voltage Range 7V~15VDC
Noise 76.5 dB(A)
Air Flow 175.0 CFM (4.90m3/min)
Fan Type Tubeaxial (Dual)
Bearing Type Ball
RPM 12500 Front, 11000 Rear
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, cURus, TUV
Current Rating (Amps) 6.20A
Voltage - Rated 12VDC
Power (Watts) 74.4W
Termination 4 Wire Leads per Fan
Part Status Active
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Size / Dimension Square - 80mm Lx80mm H
Series GFC
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
